Specifications

• Camera/VTX: Caddx Polar Vista Digital HD System

• Board: Beast F7 55A AIO board

• Motors: XING2 2506 1850KV

•  Uses the Runcam HD Camera

•

FRAME // Mach R5

• Middle Plate thickness: 2.5mm CNC 7075 aluminum alloy

• FPV Cam: 14mm /19mm Micro / 20mm

• FC: 30.5*30.5/25.5*25.5mm/20*20mm

• Main body dimension: 152*152mm

• Bottom plate thickness: 3mm

• Top plate thickness: 2.5mm

• Arm thickness: 6mm

• Wheelbase: 215mm

• TPU Camera plate

•

FC // Beast F7 AIO

• Mounting pattern: 25.5x25.5mm /3mm

• FC Firmware: IFLIGHT_F745_AIO

• Blackbox: 8Mb Onboard Flash

• Dimensions: 32.5*32.5mm

• MCU: BGA-STM32F745

• Connector: Micro-USB

• BEC output: 5V 2.5A

• Barometer: BMP280

• Gyro: MPU6000

• OSD: AT7456E

• Weight: 8.5g

•

ESC // 55A 2-6S

• Mounting pattern: 25.5x25.5mm/3mm

• ESC Firmware: BlheliS G-H-30 BLS

• Dimensions: 32.5x32.5mmg

• Constant: 55A / Burst: 60A

• Current Sensor: Yes

• Current scale: 200

• BLHeli: BLHeli-S

• Input: 2-6S LIPO

• Telemetry: no

• UARTs: 5
