ToolkitRC DC Charger M6D Dual Channel 250w 15Ax2


M6D is a dual-channel balanced charger product. Small size, high power density, innovativedesign, charging accuracy can be as lowas 5mV..

 Charge, discharge and balance managementofLiPo, LiHV, LiFe Lion 1-6S, NiMh 1-16S, PB1-10Sbatteries.

 Charging current:Synchronous mode maximum25A@MAX500WAsynchronous mode maximum15A@MAX250W

 Discharge current:Recycle mode maximum15A @250W*2Normal mode maximum3A @12W*2

 Lithium battery cut-off voltage canbeset (TVCfunction).

 Constant current and constant voltageoutput, customizable 1-28V constant voltage, 1-15Aconstant current.

 Can be adapted to mainstreamUAVbatteries, automatically activated and charged.

 Multi-language system, can arbitrarilyupgradetherequired language. 7 @ToolkitRC2020 USB 2.1A@5.0V output, rechargeablemobiledevice.

 The device connects to PC like a USBdriveforeasyfirmware upgrades. Simply copy andpastenewfirmware files to update.


SpecificationInput: 7-28V@MAX30ABattery Type: LiPo LiHV LiFe Lion@1-6S NiMh @1-16S Pb @1-10SBal Current: 800mA @2-6SAccurac: <0.005VCharging Power: 0.1-15A@250W *2 (Asynchronous mode) 0.1-25A@500W (Synchronous mode)Discharging Power: 0.1-15A@250W*2 Recycle Mode 0.1-3A@12W*2 Normal ModeUSB: 2.1A @ 5V USB3.0Battery cell Voltage: 1.0V-5.0V @1-6SBattery Internal Resistance: 1-100mR @1-6SDisplay LCD: IPS 2.4 inch 320*240 resolutionSize: 98mm*68mm*35mmWeight: 220gPackage Details: 108.5mm*80.5mm*46m 300g

ToolkitRC DC Charger M6D Dual Channel

Out of Stock
